Equipment Features
- High-Performance Energy Storage: 1.1MWh rated capacity with ≥990kWh discharge energy, delivering ≥90% AC round-trip efficiency. Supports 5%-95% state-of-charge (SOC) dynamic dispatch for optimized energy utilization.
- Modular Architecture: All-in-one integrated solution supports plug-and-play, significantly reducing installation time while enabling convenient operation and maintenance.
- Intelligent Monitoring: EMS-BMS integration achieves dynamic energy balancing and real-time fault detection, significantly reducing maintenance workload.
- Industrial-Grade Resilience: IP54-certified enclosure (dust/water jet resistant) with -20°C~50°C operational range. Engineered for complex environments including industrial parks and coastal ports.
- Multi-Layer Safety Protection: Equipped with an AEROSOL fire extinguishing device and an air-cooling temperature control system.
- Power Conversion System(PCS): Matching 500kW PCS utilizing three-level topology technology to maximize system conversion efficiency, reduce losses, and achieve medium/high-voltage grid-connected adaptation.
