5.12KWH Residential ESS-NILE-R-100

NILE-R-100
  • High quality lithium iron phosphate
  • Built-in BMS intelligent protection
  • Supports parallel connection
  • Applicable to on-grid and off-grid
  • Screen switching inverter protocol
  • productshow-icon01_140582
  • productshow-icon06_140579
  • productshow-icon04_140580
  • IEC
  • IP20

Equipment Features

  • Extreme Safety Protection: Featuring high-quality lithium iron phosphate (LiFePO₄) battery cells with up to 6000 cycles. Integrated RS485 and CAN bus communication interfaces.  Built-in BMS for real-time monitoring of abnormal data(overcharge/over-discharge/short circuit/temperature) .
  • Flexible & Efficient Design: Supports parallel connection of multiple modules; Equipped with on-grid and off-grid systems, suitable for renewable energy such as solar and wind power, with high-capacity energy storage supporting up to 100A continuous discharge.
  • Outstanding Environmental Adaptability‌: Charging working 0℃~40℃, discharging working -20℃~40℃, IP20 protection level with humidity resistance 5%~80%.
  • Intelligent & Convenient Operation: Equipped with display for real-time monitoring of voltage, capacity and current and other parameters, supporting inverter protocol switching and compatible with various inverter systems.
  • Certified Safety Assurance: Fully compliant with CE, IEC, UN38.3 and MSDS international standards.

Explore Victory Technology’s innovative energy solutions
for a sustainable future.

Product Features

  • Maximum 100A charge and discharge current
  • High-capacity energy storage
  • Longer usage time
  • Safety and Environmental Protection
  • High cycle count（6000）
  • Intelligent BMS system
  • High-quality battery cell
  • Optional communication(RS485 & CAN )

Product Description

This product is engineered for premium energy storage applications, featuring high-quality lithium iron phosphate (LiFePO₄)  battery cells, that deliver higher energy density, more reliable performance and longer service life than conventional batteries.
The system supports high-current operations up to 100A for both charging and discharging, enabling seamless power supply for high-load appliances including refrigerators, air conditioning units, and washing machines. Pure sine wave output ensures power stability and  equipment protection.

Our products integrate RS485 and CAN bus communication interfaces, complemented by an intelligent BMS that provides real-time monitoring of overcharge, over-discharge, short-circuit, and thermal anomalies to guarantee operational safety and system efficiency. The optimum operating temperature ranges support charging from 0°C to 40°C and discharging from -20°C to 40°C, covering most climatic requirements. Certified to deliver 6,000 cycles, the product features an IP20-rated housing that maintains operational integrity across 5-80% humidity ranges, ensuring reliable performance under extreme environmental conditions.

Its flexible dual-mode architecture supports both grid-tied and off-grid configurations, enabling seamless integration with solar, wind, and other renewable energy systems. Suitable for energy-independent households, off-grid installations, critical appliance backup power, medical equipment power supply, and outdoor workstation electrification, etc. This product is your optimal choice for efficient, stable and sustainable energy management.

Product Specifications

PRODUCT PERFORMANCE NILE-R-100
STANDARD VOLTAGE 51.2V
RATED CAPACITY 100AH
RATED POWER 5.12KWH
OPERATING VOLTAGE 42V-58.4V
STANDARD CHARGING CURRENT 50A
MAXIMUM CHARGE CURRENT 100A
MAXIMUM DISCHARGE CURRENT 100A
OPERATING TEMPERATURE RANGE 0~40℃(CHARGE)  -20~40℃(DISCHARGE)
STORAGE TEMPERATURE -10℃~35℃(1MONTH) 25±2℃(3MONTH)65%±20%RH
COMMUNICATION CAN&RS485
CYCLE LIFE 6000
SIZE(L*W*H) 600*430*160mm
WEIGHT 50KG
HIGH 0-3000
WATER PROOF GRADE IP20
HUMIDITY RANGE 5~80%
